Moto Guzzi Releases Full Details and Specifications for New V85 TT



Comfort seats: a complete range of seats that increase comfort levels thanks to a special 3D insert. Available in three different heights.

Clutch and brake lever: machined from solid, they improve ergonomics by offering four-position adjustment.

Additional LED lights: with an aluminum body and contained size, the lights use limited power. They integrate perfectly with the bike and allow for greater visibility and safety during night-time riding.

Foldaway mirrors: They fold in on themselves towards the handlebar, to reduce bulk during off-road use.

Mudguard: Created in injected plastic material, it is mounted on the shaft drive and protects the engine from stones and water.

Sport Adventure tires: Michelin Anakee Adventure, as standard on special versions.

High grip brake pedal: laser-cut and power painted in a resistant material. Ensures perfect grip even in the most extreme situations.

Moto Guzzi Multi-media Platform: the new device that allows for a smartphone to be connected to the bike, transforming it into a real multimedia platform.

Electronic anti-theft system: comprises a compact and technologically advanced ECU that is easy to install. Complete with remote control. The system is self-powered with minimum energy absorption.

Light protection: an anti-impact, scratch-proof polycarbonate sheet. Protects the light from any impact or accidental damage. Particularly useful on off-road routes.

Tool bag: created in leather, it can be affixed to the luggage rack with screws. Practical for keeping all those tools needed for an emergency repair (tools not included).

Fuel tank cover: in adhesive 3D material, they provide superficial protection for the tank and limit rider sliding.

Moto Guzzi V85 TT: technical specifications

ENGINE
Type Transverse 90° V twin, two valves per cylinder (titanium intake).
Cooling Air
Engine capacity 853 cc
Bore and stroke 84 x 77 mm
Compression ratio 10.5: 1
Maximum power 80 HP (59 kW) at 7,750 rpm
Torque 80 Nm at 5,000 rpm
Fuel system Electronic injection; Ø 52 mm single throttle body, Ride-by-Wire
Fuel tank capacity 21 liters (including 5-liter reserve)
Approval Euro 4
Consumption (WMTC cycle) 4.9 l/100 km
CO2 Emissions (WMTC cycle) 118 g/km

TRANSMISSION

Clutch Dry single disc
Transmission 6 gears
Gear ratio values 1st 16/39 = 1: 2.437
2nd 18/32 = 1: 1.778
3rd 21/28 = 1: 1.333
4th 24/26 = 1: 1.083
5th 25/24 = 1: 0.960
6th 27/24 = 1: 0.889
CHASSIS
Frame High strength steel tubular frame
Front suspension 41 mm hydraulic telescopic USD fork, with adjustable spring preload and hydraulic rebound
Front wheel travel 170 mm
Rear suspension Double-sided swingarm in box-type aluminum with a single shock on the right side, with adjustable spring preload and hydraulic rebound
Rear wheel travel 170 mm
Front brake Double 320 mm stainless steel floating discs, Brembo radial-mounted calipers with 4 opposed pistons
Rear brake Ø 260 mm stainless steel disc, floating caliper with 2 pistons
Wheels Spoked
Front wheel rim 2.50” x 19”
Rear wheel rim 4.25” x 17”
Front tire With air chamber 110/80 – R19”
Rear tire With air chamber 150/70 – R17”
ELECTRICAL SYSTEM
A/C generator 430 W
System voltage 12 V
Battery 12V – 12 Ah
DIMENSIONS
Saddle height 830 mm
Dry weight 208 kg
Curb weight* 229 kg

* Weight with motorcycle ready for use, with all operating fluids and 90% fuel.
